Alloy Steel Subsurface Sucker Rod Pump Borehole Drilling

  • 1
  • 2
  • 3

Brand Name : PUYANGZHONGSHI

Model Number : API or customized

Certification : API 11AX-0061

Place of Origin : Puyang city , Henan province ,China

MOQ : 1pcs

Price : USD 300-500$/pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100pcs,one month

Delivery Time : 20-30 work days

Packaging Details : wooden cases

Material : AISI 4130, 20CrMoA, alloy steel etc

Use : Borehole Drilling

Color : Customer's Requirement

Type : Sucker Rod pump

Machine type : Drilling Tool

Standard : API

Name : sucker rod pump

Contact Now

The rod pump is connected to sucker rod after being assemblied on the surface then it is pulled down to the well bottom through the tubing. Thus it is convenient for the inspection and workover because they can be pulled up and down through the tubing and suitable for deeper well. The life span of tubing can be prolonged for decreasing the times of the thread of the tubing being turned on and off and the time of the workover. The rod pump can be classified into two types of mechanical seating and cup seating. Also it is divided into three types as RHA (stationary heavy well barrel top anchor rod pump), RHB (stationary heavy well barrel bottom anchor rod pump) and RHT (travelling heavy well barrel bottom anchor rod pump).

Product Models and Specifications:

Model mm(in)
Nominal Dia.		 m(ft)Plunger
Length		 Stroke m m3/d Pump
Constant		 Tubing And
Thread		 In Sucker
Rod
20-125TH 32(1.25) 1.2-1.8 (4-6) 0.6-7.3 1.14 27/8NU/EU ¾
20-125RHAC/M 32(1.25) 0.6-7.3 1.14 27/8NU/EU ¾
20-125RHBC/M 32(1.25) 0.6-7.3 1.14 27/8NU/EU ¾
20-125RHTC/M 32(1.25) 0.6-7.3 1.14 27/8NU/EU ¾
25-125TH 32(1.25) 0.6-7.3 1.14 27/8NU/EU ¾
25-150RHAC/M 38(1.50) 0.6-7.3 1.64 27/8NU/EU ¾
25-150RHBC/M 38(1.50) 0.6-7.3 1.64 27/8NU/EU ¾
25-150RHTC/M 38(1.50) 0.6-7.3 1.64 27/8NU/EU ¾
20-150TH 38(1.50) 0.6-7.3 1.64 27/8NU/EU ¾
25-150TH 38(1.50) 0.6-7.3 1.64 27/8NU/EU ¾
20-175TH 44(1.75) 0.6-7.3 2.24 27/8NU/EU ¾
25-175RHA/M 44(1.75) 0.6-7.3 2.24 27/8 ¾
25-175RHB/M 44(1.75) 0.6-7.3 2.24 27/8NU/EU ¾
25-175RHT/M 44(1.75) 0.6-7.3 2.24 27/8NU/EU ¾
25-175TH 44(1.75) 0.6-7.3 2.24 27/8NU/EU ¾
25-225TH 57(2.25) 0.6-7.3 3.69 27/8NU/EU ¾
30-275TH 70(2.75) 0.6-7.3 5.50 3½NU/EU 7/8
30-225RHC/M 57(2.25) 0.6-7.3 3.69 3½ NU/EU ¾
30-225RHC/M 57(2.25) 0.6-7.3 3.69 3½ NU/EU ¾
30-225RHC/M 57(2.25) 0.6-7.3 3.69 3½ NU/EU ¾
35-325TH 83(3.25) 0.6-7.3 7.70 4NU/EU 7/8
40-375TH 95(3.75) 0.6-7.3 10.26 4½NU/EU 1

Alloy Steel Subsurface Sucker Rod Pump Borehole DrillingAlloy Steel Subsurface Sucker Rod Pump Borehole DrillingAlloy Steel Subsurface Sucker Rod Pump Borehole Drilling

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 1-5days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:

Contact us

Tel:+ 86-393-4807842

Mobile / wechat/whatsapp: + 86-15839373570

Address: Puyang City, Henan Province, China

Website: http://www.zspetro.net/lm.asp?id=1

http://russian.sucker-rodpump.com/
