Mechanical Anchor Heavy Wall Thin Wall SRP Pump

Name: Mechanical Anchor Heavy Wall Thin Wall SRP Pump
Brand: Zhongshi
Price: 1 USD

Brand Name : Zhongshi

Model Number : Sucker rod pump

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Type of seating assembly : Mechanical anchor

Location of seating assembly : Bottom and top

Pump barrel : Heavy walled and thin walled

Certificate No. : API 11AX-0061

Barrel : 45# steel with chrome plated coating

Plunger : 45# steel with spray metal

Contact Now

Mechanical Anchor Heavy Wall And Thin Wall Suker Rod Pump

Mechanical Heavy Wall And Thin Wall Sucker Rod Pump Description

Mechanical anchor rod pump with thin wall and heavy wall can be withstand higher oil well temperatuer than the cup type. This kind of rod pump is also equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work. If the pump appeared quality problem,it need not to put out of the tubing string, only through rod string together put out of the whole pump, operation is simple. Mechanical anchor rod pump can withstand high oil well temperature.

Technical parameter list:

Heavy walled list

Specification	Pump diameter (in)	Barrel length (ft)	Plunger length (ft)	Stroke length (ft)	Extension length (ft)	Tubing size EUE(in)
15-106RHBM	Ø26.99	2.1-10.4	0.3-8.0	1.2-9.0	0.3-0.9	1.9"
20-125RHAM	Ø31.75					2-3/8”
20-125RHBM
25-150RHAM	Ø38.1					2-7/8”
25-150RHBM
25-175RHBM	Ø44.45
25-175RHAM
30-225RHAM	Ø57.15					3 1/2"
30-225RHBM

Thin walled list

Specification	Pump diameter (in)	Barrel length (ft)	Plunger length (ft)	Stroke length (ft)	Extension length (ft)	Tubing size EUE(in)
20-125RWAM	Ø31.75	2.1-10	0.3-8.0	1.2-9.0	/	2-3/8”
20-125RWBM
20-150RWAM	Ø38.1					2-7/8”
20-150RWBM
25-200RWAM	Ø50.80
25-200RWBM
30-250RWAM	Ø63.50					3 1/2"
30-250RWBM

Features

1. Mechanical seating locations: top and bottom
2. There two kinds of mechanical seating sucker rod pumps: heavy wall rod pump and thin wall rod pump

4. Mechanical rod pump are running inside the tubing with the support joint ,it is suitable for high temperature of deep well
