Thin Walled Mechanical Top Seating Sucker Rod Pump

Brand Name : Zhongshi

Model Number : Sucker rod pump

Certification : API, ISO, QHSE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, D/A

Supply Ability : 1000 SETS/MONTH

Delivery Time : 10~15 workdays

Packaging Details : Standard exported packing

Type seating assembly : Mechanical

Location of seating assembly : Top

Pump barrel : Thin walled

Plunger coating : Spray metal

Barrel material : AISI 1045 steel

Certificate No. : API 11AX-0061

Contact Now

Thin Walled Mechanical Top Seating Suker Rod Pump

Mechanical Top Seating Sucker Rod Pump Description

Mechanical top seating sucker rod pump is a kind of thin wall rod pump. This kind of rod pump is also equipped with a support joint, support joint connected on the tubing string, and it is together with the tubing string down to the bottom. Plunger assembly is connected on the rod string and together with the whole pump down to support joint position, pump is fixed within the support joint by external force, plunger assembly is together with the sucker rod string up and down reciprocating movement to achieve pumping work.When inspection and maintenance pump,it need not to put out of the tubing string, only through rod string together put out of the whole pump, operation is simple. Mechanical seating pump can be suitable for higher oil well temperature, but the thin wall pump is not endurable as heavy wall pump.

Technical parameter list:

Specification Pump diameter (in) Barrel length (ft) Plunger length (ft) Stroke length (ft) Extension length (ft) Tubing size EUE(in)
20-125RWAM Ø31.75 2.1-10 0.3-8.0 1.2-9.0 / 2-3/8”
20-125RWBM
20-150RWAM Ø38.1 2-7/8”
20-150RWBM
25-200RWAM Ø50.80
25-200RWBM
30-250RWAM Ø63.50 3 1/2"
30-250RWBM

Features

.
1. Thin wall barrel mechanical seating rod pump

2. Mechanical rod pump are running inside the tubing with the support joint ,it is suitable for high temperature of deep well

Thin Walled Mechanical Top Seating Sucker Rod Pump
