Oilfield Drill Rod Coupling Metal Polished Sucker Rod Coupling

Name: Oilfield Drill Rod Coupling Metal Polished Sucker Rod Coupling
Brand: Zhongshi
Price: 1 USD

Brand Name : Zhongshi

Model Number : sucker rod

Certification : API ,ISO ,QHSE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 1000pcs

Delivery Time : 2weeks

Packaging Details : exported packing

Product name : Alloy Steel Sucker Rod

Grade : D,KD,HY,K,HL

Standard : API 11B

Size : 3/4",1",5/8"-1-1/8"

Length : 25-30ft

Package : Bundle as per API 11B standard

Contact Now

Sucker Rod Introduction:

A "sucker rod" is a long, slender, and flexible rod used in the oil and gas industry to transmit power from a surface pumping unit to downhole pumping equipment such as a pumpjack. Sucker rods are typically made of high-strength steel and are connected in a series to create a rod string that extends down into the wellbore. These rods are essential for transferring the reciprocating motion from the surface to downhole pumps, allowing for the extraction of oil or other fluids from the well.
All sizes of sucker rod (standard, heavy, polish rod) which conform to API specification latest version 11B are available in grade K, C, D and HL.

Size in (mm)	Rod Body diameter in (mm)	diameter of ext. thread in (mm)	Full size Coupling OD mm (in)	Coupling OD mm (in)	Wrench square W*L mm (in)	Length series m (ft)
5/8 (16)	5/8 (15.88)	15/16 (23.81)	38.10(1.5)	31.8 (1.25)	22.2×31.8 (7/8×1-1/4)	7.62 (25)
3/4 (19)	3/4 (19.05)	1-1/16(26.99)	41.28(1.625)	38.1 (1.5)	25.4×31.8 (1×1-1/4)	9.14 (30)
7/8 (22)	7/8 (22.23)	1-3/16 (30.16)	46.0(1.812)	41.3 (1.625)	25.4×31.8 (1×1-1/4)	0.6 (2), 1 (3)
1 (25)	1 (25.40)	1-3/8 (34.93)	55.6(2.187)	50.8 (2)	33.3×38.1(1-5/16×1-1/2)	2 (6), 3 (10)
1-1/8 (28)	1-1/8 (28.58)	1-9/16 (39.7)	60.33(2.375)	57.2 (2.25)	38.1×41.3 (1-1/2×1-5/8)

Mechanical Properties of Sucker Rods:

Grade	Min Yield strength 0.2% offset M Pa (psi)	Tensile strength M Pa (psi)	Elongation δ%	Reduction of area ψ%
K	414 (60, 000)	621-793(90, 000-115, 000)	≥13	≥60
C	414 (60, 000)	621-793(90, 000-115, 000)	≥13	≥50
D	586 (84, 970)	793-965 (114, 985-139, 925)	≥10	≥50
KD	590(85, 000)	793-965 (114, 985-139, 925)	≥10	≥50
HL	795(115,000)	965-1,195(140,000-173,339)	≥10	≥45
HY	540 (78, 300)	965-1,195(140,000-173,339)	≥42	≥224

Oilfield Drill Rod Coupling Metal Polished Sucker Rod Coupling
